K160 DC inline ventilation fan 48V PWM control from China manufacturer

K160 DC inline ventilation fan 48V PWM control

Payment Terms:	T/T,L/C
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: CDFD160

Production Capacity: 2000-3000PCS per month

Delivery Date: 30 days for 5000 pcs After ...

Certification: CE

Material: galvanized sheet steel hous...

Diameter sizes: 160/6.3 inch

Approvals: CE, CCC

Operation Temperature: -10° C to 40° C

Speed Control: 0-10VDC/PWM

Means of Transport: Ocean,Land,Air

Packing: PALLET

Type: Others

Brand Name: Green Power

Type of protection: IP44

Insulation class: F

Bearings: Maintenance-free ball beari...

Voltage: 24/48VDC

Air flow: 411CFM

160mm size Circular duct and galvanized sheet steel casing, energy saving 30%~40%, 100% speed controllable, Integrated protection, Easy to connect

Features:

·12V, 24V or 48V available
·411CFM
·Brushless DC Motor, high efficiency,low noise

·speed regulation for 100%

·Integrated protection

·supply mounting bracket

Specs:

Model

Impeller size (mm)

Voltage (DC)

Voltage range

Airflow (CMH) (CFM)

Power (Watt)

Current (Amp)

Speed (RPM)

Static Pres.(Pa)

Noise (dB)

Package Size (cm)

N.W/G.W (kg)

CDFD100

190x45-DC92

48V

up-72Vdc

365

211.7

1.66

3240

475

30x26.5x23.5

2.3 / 3.5

CDFD125

190x45-DC92

48V

up-72Vdc

403

233.7

1.67

3240

480

30x26.5x23.5

2.4 / 3.6

Curves:
High efficiency 48v DC Inline Duct Fan with 220 EC centrifugal fan K160

Outlines:

GP Inline Duct Fan can provide fresh air wherever people are present. Reducingthe energy use and high efficiency,It also can been easy to connect and their ballbearing motor to speed control.
