133 Brushless DC Centrifugal Fan 48V speed regulation-R1G133
| Payment Terms: |
T/T,L/C |
| Place of Origin: |
Zhejiang, China (Mainland) |
Product Detail
Model No.:
R1BE133/041
Production Capacity:
5000PCS per month
Delivery Date:
30 days for 5000 pcs After ...
Certification:
RoHS
Material:
Fibreglass-reinforced PP
approvals:
CCC,CE
Impeller Dimension:
133mm
weight:
0.7KGS
USES:
ventilation
Means of Transport:
Ocean,Land,Air
Packing:
PALLET
Type:
Chiller
Brand Name:
Green Power
Type of protection:
IP22
Insulation class:
B
Blade height:
41mm
power:
28.5W
speed:
3910RPM
GP DC backward curved Centrifugal Fan has outer rotor brushless DC motor,Integrated electronics,0-10/PWM control, 30~40% Energy-saving, like emc,ebm.
Green power 24V Backward DC Centrifugal Fan impeller noise reduce-RB1D133 data sheet
| Rated voltage | 24 | 48 | VAC |
| Rated voltage range | 16~28 | 36~57 | VAC |
| Power input | 28.5 | 28.5 | W |
| Speed | 3910 | 3910 | RPM |
| Airflow | 365 | 365 | M3/H |
| Current draw | 1.32 | 0.73 | A |
| Noise | 63 | 63 | dBA |
| Min.ambient temperature | -25 | -25 | oC |
| Max.ambient temperature | 60 | 60 | oC |
| Net weight | 0.7 | 0.7 | kg |
Green power 24V Backward DC Centrifugal Fan impeller noise reduce-RB1D133 technical drawing:
DC Centrifugal Fan with backward curved blades are popular to replace the traditional AC Fan technology in ventilation, air-conditioning, and refrigeration systems.
Green power 24V Backward DC Centrifugal Fan impeller noise reduce Primary Competitive Advantages:
· A highly efficient 24/48/56 VDC motor
· Full on-board electronic
· Locked Rotor protection
· Constant speed, volume, pressure options
· Fully controllable through 0-10V/PWM signal
· EMC and ErP 2015 compliant
· High-efficiency,space-saving
· Significantly lower specific fan powers than the AC equivalent.
· Extended service life and
cooler, quieter operations .
· meet the needs of low carbon reduction.
