Energy-saver Brushless DC Motor efficiency 12V
| Payment Terms: |
T/T,L/C |
| Place of Origin: |
Zhejiang, China (Mainland) |
Product Detail
Model No.:
ECI-4548-9
Production Capacity:
10000pcs/m
Delivery Date:
25days
Shape:
Tubular
Protect Feature:
Enclosed
Function:
Driving
Brand Name:
Green Power
Rated Speed:
5000rpm
Rated Current:
1.5A
Means of Transport:
Ocean,Land,Air
Packing:
Pallet
Structure:
Others
Phase:
Three Phase
Speed:
High Speed
Usage:
Others
Voltage:
12V
Torque:
0.02N.m
Power:
9.5W
We offer a range of Brushless DC motors for automobile, robotics,medical facilities, industrial automation and security technology, high performance.
GP DC Brushless motors are designed as brushless, grooved external or internal rotor motors, the advantages being the rotor's low inertia, minimal detent, robust bearings and compact construction. The use of high-powered permanent magnets ensures high power density, providing great speed stability under load. The modular system with gearheads, encoders and controllers from the GP delivery program offers a large number of possible combinations.
brushless dc motors are ideally suited for automobile,robotics,medical facilities, industrial automation and security technology.
| Model | Rated Voltage (VDC) | Output Power (Watt) | Nominal Torque (N.M) | Phase | Nominal Speed (RPM)) | No load Speed (RPM)) | Rated Current (A) | No Load Current (A) | 3 Pola (P) |
| EC-I5774-21 | 14 | 24 | 0.11 | 3 | 1850 | >1850 | 2.80 | 0.33 | 4 |
| Model | Rated Voltage (VDC) | Output Power (Watt) | Nominal Torque (N.M) | Phase | Nominal Speed (RPM)) | No load Speed (RPM)) | Rated Current (A) | No Load Current (A) | 3 Pola (P) |
| EC-I70125-183 | 130 | 183 | 0.35 | 3 | 5000 | 6600 | 3.00 | 0.25 | 4 |
