Outdoor cabinet telecom air condition Brushless DC Fan
| Payment Terms: |
T/T,L/C |
| Place of Origin: |
Zhejiang, China (Mainland) |
Product Detail
Model No.:
R1FE146/062
Production Capacity:
5000PCS per month
Delivery Date:
20~25 days
Certification:
CE
Cooling/Heating:
Others
Materials(impeller):
Galvanised sheet steel
Insulation Class:
B
Operation Temperature:
-30° C to 65° C
Airflow:
210m3/h
Weight:
1.4KGS
Means of Transport:
Ocean,Land,Air
Packing:
Carton/Pallet
Type:
Central Air Conditioners
Capacity:
Others
Brand Name:
Green Power
Materials(housing):
scroll
Type of protection:
IP44
Voltage:
24/48/56VDC
Speed:
3050RPM
vantage:
energy-saving(30%)
Integrated protection,simple controllability
easy, quiet, efficient speed control,lower running cost
0-10VDC or PWM signal output
similar EBM
Single inlet Telecom air conditioner Brushless DC Fan are widely used in Telecommunication(FCU and Heat exchanger), cleaning room,Building ventilation system, HVAC, Railway technology,Purification business.
Telecommunications
Single inlet Brushless DC Fan from GP Motor are widely used in these air conditioning units in switch cabinets, electrical equipment rooms,containers and shelters,etc. operating temperature of the sensitive transmission technology stable can be kept by telecommunication air-conditioning systems in switch cabinets, containers and shelters.
Clean rooms
Single inlet Brushless DC Fan used in Precision Air Conditionerscan can offer no heat loads to deal with,ensuring a sufficient throughput of air, precise temperature and humidity control and constant air quality.
Clean rooms have extremely special requirements for air-conditioning systems.
HVAC system
Single inlet Brushless DC Fan from GP are popular to replace the traditional AC Fan technology in ventilation, air-conditioning, and refrigeration systems
Single inlet Telecom air conditioner Brushless DC Fan data sheet
| Model | Voltage range (VDC) | Voltage (VDC) | Airflow (m3/h) | Power (Watt) | Speed (RPM) | Current (Amp) | Perm.amb,temp (oC) | Noise (dB) | Net (kg) |
R1FE146/062
GR1FE146/062 | 16-28 | 24 | 475 | 103 | 2250 | 4.25 | -25~+65 | 68 | 1.4/2.8 |
| 36-57 | 48 | 465 | 103 | 2200 | 2.13 | -25~+65 | 67 |
Single inlet Outdoor cabinet telecom air condition Brushless DC Fan drawing:
